Outdoor Face Recognition Terminal

NAT‑VX

Control pedestrian entry at outdoor building entrances and perimeter gates using face recognition or access cards. An IP66-rated enclosure and IK10 impact resistance suit exposed installation locations. PoE supports power and network connectivity through one Ethernet cable, while a wide-angle camera with low-light imaging supports face capture as lighting conditions change.

  • IP66 Weather Protection — Dust-tight enclosure with protection against powerful water jets for outdoor installations.

  • IK10 Impact Resistance — Impact-rated housing for exposed building entrances and perimeter access points.

  • PoE Connectivity — Carries power and network data through a single Ethernet cable.

  • Face and Card Verification — Supports face recognition, 125 kHz EM cards and 13.56 MHz MIFARE cards.

  • Low-Light Face Capture — Wide-angle camera with starlight imaging supports capture in dim entrance areas.

  • Verification Feedback — Voice prompts and a three-color indicator provide feedback, with liveness detection to help identify spoofing attempts.

NAT-VX Outdoor Facial Recognition Terminal for Harsh Environments

The NAT-VX outdoor facial recognition terminal features IP66 waterproof and dustproof rating, allowing reliable operation in both direct sunlight and rainy conditions. Equipped with dual-lens binocular cameras and infrared night vision, this outdoor facial recognition terminal performs accurately even in low-light environments. It supports face recognition, RFID card and QR code verification, and can be integrated with turnstiles, barrier gates and elevator access systems. With an operating temperature range of -20°C to 60°C, the NAT-VX is suitable for parking lots, residential communities, industrial parks and outdoor building entrances.

Capacity

Faces

30,000

Cards

30,000

Logs

200,000

Interfaces

Communication Mode

TCP/IP, WiFi, Bluetooth

I/O

Relay, Wiegand input/output, RS232, RS485, Door sensor, Exit button, Fire alarm

Functions

Face Recognition

Live detection

Upgrade Mode

Online

Recognition Modes

Face, Card, Face + Card

Hardware Specifications

Memory

8GB ROM + 512MB RAM

CPU

Dual-core ARM Cortex-A7 MP2@1GHz, Linux

Card Modules

Standard EM and MIFARE Card, NFC

Cameras

IR, RGB dual-lens camera, Starlight wide-angle camera

LEDs

One tri-color indicator LED, Two Infrared Fill-in LEDs

General

Working Temperature

-40°C ~ 65°C

Storage Temperature

-20°C ~ 60°C

Working Humidity

10% ~ 90%

Power Supply

DC 12V/2A / DC 12V/2A, POE 802.3af

Power Consumption

Max. 10W

Device Dimensions

56 mm × 183 mm × 34.6 mm

Certificates

CE, FCC

Where the NAT-VX Outdoor Facial Recognition Terminal Is Used

The NAT-VX outdoor facial recognition terminal is commonly deployed at building entrances, parking lot access points, residential community gates, industrial park checkpoints and school perimeter entrances. Its IP66 rating and wide operating temperature range make it suitable for projects where other indoor face recognition devices cannot perform reliably. It can also be paired with barrier gates, boom barriers and automatic sliding doors to create a full outdoor access control solution for different property types.

Technical Features for Outdoor Access Control

The NAT-VX supports TCP/IP, Wiegand and RS485 communication, allowing flexible integration with existing access control panels and turnstile controllers. It includes built-in infrared night vision, ensuring accurate recognition after sunset or in covered entrance areas. The device also supports offline face database storage of up to 50,000 records, so access control continues to work even if the central network is temporarily interrupted. These features make the NAT-VX a dependable choice for outdoor deployments where stability matters.

OEM & ODM Outdoor Terminal Customization

New Auto Element provides OEM and ODM services for the NAT-VX outdoor facial recognition terminal. Distributors, contractors and system integrators can request custom logo printing, branded firmware, housing color options, protocol adaptation and private-label packaging. We also provide SDK and API documentation so the terminal can be connected to your own access management platform. Contact our engineering team for a customized solution based on your outdoor project requirements.We supply bidding documents, technical datasheets and remote technical support for commercial access control projects.

Get in Touch for Your Outdoor Access Project

Looking for a reliable outdoor facial recognition terminal for your next access control project? Share your project specifications, and our team will send you a custom quotation and product datasheet.
Explore our full access control product range or contact our sales team today.
